MASSEY FERGUSON 35/135 TRACTOR WIRING DIAGRAM

E Earth ( To tractor chassis) A Armature (No 1 on ignition switch) F Field (Small terminal on dynamo) 4mm wire 2.5mm wire 4mm wire 2.5mm wire 2.5mm wire 674 96AH battery Insulate wires with a good quality insulation tape and place in protective flexible auto wire sleeve MASSEY FERGUSON 35 WIRING DIAGRAM DIESEL 3 CYLINDER WITH DYNAMO (GENERATOR)
