How to wire PoE cameras

As you can see in the following diagram, it's necessary only to use a UTP cable from the IP camera to the NVR which is also connected to a laptop. The picture below shows an IP camera connected directly to an 8-port PoE NVR that uses the international standard 802.3af , which means the device sends 48V (volts) to the camera which can consume a power of up to 12.95W (watts).
